This is a multi-functional tube heat shrinking machine, whether the heat shrink tube is at the head or the middle of the wire, this machine can easily deal with it. Its U-shaped wire slot and retractable shrink cavity design make it particularly easy to switch heat shrink positions, especially when there are multiple heat shrink tubes in the middle of the wire.
This machine is small in size, especially suitable for use on the assembly line. It is heated by circulating hot air, the temperature in the heating chamber is balanced, and the heat shrinkable tube is heated evenly. It is often used in occasions with strict requirements on heat shrinking effect, such as the high-voltage wire processing industry of new energy vehicles.
 |  |  |
Max. Temperature: 250℃
Max. Tube Length: 80mm
Max. Tube OD: 40mm
Power Supply: 220V 50/60Hz
Power Rating: 650W
Net. Weight:
Dimension: 196×404×320mm
Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
